Drechsel (Dreschel) glass gas washing bottle with interchangeable joint head and round base. Can be used to remove impurities from gasses. Inlet / Outlet Glass tubes measure 5mm inside diameter. Total height of the bottle is approx. 11 inches. Made of borosilicate glass.
Design:
- Complete Set: Includes a reservoir bottle and a detachable head with an inlet and outlet tube.
- Inlet/Outlet Tubes: Standard glass tubes measuring approximately 8 mm internal diameter.
- Bubbling Action: The inlet tube extends to the bottom of the bottle to ensure gas bubbles through the liquid medium for maximum absorption or scrubbing efficiency.
Primary Applications
- Gas Purification: Removing impurities (like moisture or specific vapors) from a gas stream by bubbling it through a scrubbing liquid.
- Humidifying: Saturating a dry gas with water vapor.
- Gas Washing: Removing acidic or alkaline vapors from gas emissions.
How to use a gas washing bottle
- Place the gas washing bottle in a secure place.
- Fill the bottle with the choice liquid.
- Grease the joints.
- Connect the tubing to the 2 external glass tubes from the bottle, with the gas entry tube to the long tube, and the gas exit to the shorter tube.
- Begin pumping gas through the bottle.
Specifications
- Material: Clear 3.3 Borosilicate Glass
- Joint Size: Select from drop down
- Tube Connector: Glass thread Connector
- Brand: OMSONS
- Product of India
